Группа запчастей для Brother MFC8881DNHY - PAPER FEEDER


Группа запчастей для Brother MFC8881DNHY - PAPER FEEDER
Номер партии Описание Примечание
1 LM9001001 PE EG SENSOR ASSY
10 LU7184001 MP ROLLER HOLDER ASSY
11 LM5171001 PE ACTUATOR MP
12 LU0027001 PE ACTUATOR MP B 2
13 LM6490001 MP SEPARATION SPRING
14 LM6752001 SEPARATION PAD ASSY MP
15 LM5196005 TRAY MP ASSY
16 LS7305001 MP TRAY COVER ASSY, DCP8080DN/DCP8085DN/MFC8480DN/MFC8680DN
16 LS7004001 MP TRAY COVER ASSY, MFC8880DN/MFC8881DNHY/MFC8890DW
16-1 LS7283001 BROTHER EMBLEM COVER ASSY, MFC8880DN/MFC8881DNHY/MFC8890DW
16-1 LS7306001 BROTHER EMBLEM COVER ASSY, DCP8080DN/DCP8085DN/MFC8480DN/MFC8680DN
17 LU7689001 PROCESS COVER ASSY FOR INC
17 LU7037001 PROCESS COVER ASSY EXCEPT FOR CHN/IND, EXCEPT FOR MFC8881DNHY
17 LU7527001 PROCESS COVER ASSY FOR CHN, MFC8881DNHY
17-1 LM5124001 PROCESS COVER STOPPER
17-2 LU7039001 SUPPORT FLAP 1
17-3 087411016 TAPTITE CUP B M4X10
18 085310816 TAPTITE BIND B M3xE
2 LU7935001 PE ACTUATOR ASSY CHG
3 LM5132001 EDGE ACTUATOR
4 LM5133001 EDGE ACTUATOR SPRING
5 LU7179001 ROLLER HOLDER ASSY
6 LM5150001 REGIST ACTUATOR FRONT
7 LM5151001 REGIST ACTUATOR REAR
8 LM5152001 REGIST ACTUATOR SPRING
9 LJ9999001 MP PE SENSOR ASSY
