Группа запчастей для Xerox Phaser 4500 - Electrical

Группа запчастей для Xerox Phaser 4500 - Electrical
№ Номер партии Описание Примечание
1 ---- HARNESS ASSY LVPS (J10, J11, J18, J27, CNPOW, J141-J42, J41, J1821, P270, J102, P2750, J40, P142, P144, J411, J400)
10 127E83610 FAN MAIN (J244)
11 ---- PANEL REAR
12 ---- BRACKET HANDLE R
13 671-5321-80 I/P PWBA (ESS)
14 ---- SHIELD ASSY ESS
15 ---- SHIELD ASSY WINDOW
16 962K13460 FFC ASSY ESS (P28-CNVD)
17 ---- HARNESS ASSY CHUTE (J24-P245, P248)
18 ---- SHIELD PLATE HVPS
19 675K05541 HVPS/MCU 110 V
19 675K05591 HVPS/MCU 220 V
2 ---- PLATE TIE FRONT
20 ---- MYLAR HVPS
21 ---- HARNESS ASSY FDR1 (J20-P2083) (Feeder Harness 1)
23 675K04670 POWER CORD 110 V
25 ---- BRACKET SHIELD HVPS
26 ---- HARNESS ASSY OCT 1 (J30-P3070) (Stacker Harness 1)
27 ---- CAP CONNECTOR-DRAWER
28 ---- HARNESS ASSY TONER 2 (J22-P221)
3 ---- SHIELD PLATE LVPS
30 054E23162 DUCT (Upper Duct)
31 105K20440 DC-DC Converter
32 156-4663-00 256 MB RAM DIMM
32 156-4838-00 64 MB RAM DIMM
32 156-4837-00 128 MB RAM DIMM
33 671-5325-0A FLASH DIMM
34 650-4309-00 HARD DRIVE ASSY
35 163-1505-00 CONFIG CARD B TO N
36 163-1513-00 CONFIG CARD BASE
37 163-1459-00 NVRAM DEVICE
4 160K91991 PWBA EXIT MOTOR
5 105K20392 LVPS 110 V
5 105K20401 LVPS 220 V
6 110K11570 POWER SWITCH
7 110K11623 INTERLOCK S/W REAR (J44)
8A ---- HARNESS ASSY AC 110V (J48, J480)
8B ---- HARNESS ASSY AC 220V (J48, J480)
