Группа запчастей для Samsung SL-M3870FD_4070_4075XEV - FRAME-ETC


Группа запчастей для Samsung SL-M3870FD_4070_4075XEV - FRAME-ETC
Номер партии Описание Примечание
1 JC61-04064A GUIDE-FRAME DUPLEX; ML-3700,ABS,2.3,250,5
10 JC47-00036B CLUTCH-ELECTRIC; 2.5,45,0.6,120mA,200Ohm
11 JC66-02778A GEAR-EXIT IDLE 96; ML-3310,POM,0.5,96,NTR
12 JC66-02780A GEAR-EXIT 65; ML-3310,POM,0.5,65,NTR,F20-
13 JC63-02875A GROUND-BRKT GEAR; ML-3700,SUS,0.2,18,18,G
14 JC72-00983A LOCK SLIDER; ML-1710,POM(DELIN 900P),WHT
15 JC61-00604A PLATE-P-SAW; ML-1400,SUS304,0.15,15.1,216
16 JC66-02834A ROLLER-FEED REGI; ML-3200,EPDM,SUM22,6
17 JC66-02762A ACTUATOR-EMPTY; ML-3710,POM,3.0,43.1,31.2
18 JC66-02763A ACTUATOR-REGI; ML-3710,PC+GF,3.0,30.6,21.
19 JC66-02764A ACTUATOR-FEED; ML-3710,PC+GF,3.0,17.5,20.
2 JC63-02956A SHEET-DUPLEX PATH; ML-3710,PET+TAPE NITTO
20 0604-001393 PHOTO-INTERRUPTER; TR,75mW,BGA,TR
21 JC61-02752A FRAME-DUPLEX PATH_EX; ML-2851ND,HIPS,BLAC
22 JC61-04069A PLATE-FRAME BOTTOM; ML-3700,EGI-SECC,1.0,
23 JC66-01022A ROLLER-M_IDLE SCF; SCX-6345N,POM,500CL
24 JC67-00291A CAP-HARNESS; ML-2851ND,ABS V0,2,241.1,76.
25 JC61-02265A BRACKET-SWING DUPLEX; ML-2851ND/XAA,PPS,5
26 JC66-01651A GEAR-RDCN 23/23; ML-2851ND/XAA,POM,0.6/0.
27 JC31-00146A FAN; Type4,24,100mA,2.794mmH20,0.374m^3/m
28 JC70-40912A SHAFT; ML-5000A,STAINLESS-STS303,6,NI,T4.
29 JC93-00324A FRAME-ROLLER DECURL; ML-3700
3 JC61-00585A BUSH-M-FEED IDLE; ML-1710,POM,2.1,4.2
30 JC63-02874A GROUND-BRKT PAPER; ML-3700,SUS,0.2,54,43.
31 JC63-02876A GROUND-HVPS; ML-3700,SUS,0.2,74.3,15,GROU
32 JC63-02877A GROUND-BRACKET LSU; ML-3700,SUS,0.2,48.5,
33 JC44-00197A HVPS; 24V,21.6V~27.6V,MAX 5KV,MAX-2KV,600
34 JC93-00323A FRAME-ROLLER EXIT; ML-3700
35 JC67-00055A BRUSH-ANTISTATIC 531P; SF-531P,AL+THUNDER
36 JC61-04067A HOLDER-EXIT SENSOR; ML-3710,ABS,2,45.5,44
37 JC66-01635A GEAR-SWING DR 19;
38 JC61-04915A BRACKET-LSU; ML-3750ND,EGI-SECC,1.0T,305,
39 JC61-04091A GUIDE-TR RIB; ABS,2.3,239.2,79.8,BLACK,PA
4 JC61-00914A PLATE-P-PUSH BUSHING; SCX-4920N,EGI-SECC,
40 JC66-02842A ROLLER-TRANSFER; Magpie,15.0 (mm),NBR+ECO
41 JC61-02236A PLATE-EARTH-TRANSFER; ML-2851ND,EGI-SECC,
42 JC72-00985A CORE ROTOR; ML-1710,POM(M90-44),BLK
43 JC65-00047A TERMINAL-TR; ML-3700,SUS304,0.5PI
44 6502-001130 CABLE CLAMP; DACS-3N,16.67 * 4,Nylon66,BL
45 JC72-41191B SHAFT; ML-2150,POM,BLK,DE8903
46 JC73-00340A RUBBER-PICK UP; ML-3700,EPDM80%+IR20%
48 JC63-04078A SHIELD-CONTROLLER; SL-M4025ND,EGI-SECC,0.
49 JC39-01469A HARNESS-REARCOVER & BINFULL SENSOR; ML-3710
5 JC66-00527A SHAFT-FEED IDLE; ML-1510,SUM 24L,223,8,ST
50 JC39-01482A HARNESS-AC INLET-1; ML-3710,UL1617,3pin,W
51 JC61-04912A HOLDER-BRKT_LSU_RIGHT; ML-3750ND,PC+GF,T2
52 JC61-04911A HOLDER-BRKT_LSU_LEFT; ML-3750ND,PC+GF,T2.
53 JC63-03449A GROUND-BRKT EXTENSION; ML-3750ND,SUS,0.2,
54 JC66-03311A GEAR-FEED IDLE 29;
6 JC66-02770A LEVER-COUPLING; ML-3710,PC,3.0,184.4,126.
7 JC60-00037A SPACER-CLUTCH; ML-2851ND/XAA,POLY,ID4,OD1
8 JC66-02797A ROLLER-FEED; ML-3700,EPDM,SUM22,5
9 JC47-00033A CLUTCH-ELECTRIC; 2.5,24,1,120mA,200Ohm
