Группа запчастей для Brother HL4200CN - CHUTE ASSY IN


Группа запчастей для Brother HL4200CN - CHUTE ASSY IN
Номер партии Описание Примечание
1 LM0421001 CHUTE ASSY IN BR 120V
10 LM0423001 HARNESS ASSY FSR3C 120V
11 LM0424001 HARNESS ASSY FSR32C 220V
12 LM0200001 HARNESS ASSY CTD
13 LM0021001 HOLDER ASSY CTD
14 LM0201001 SPRING CTD
15 LM0022001 SENSOR TNR FULL
16 LM0202001 HARNESS ASSY TFLSNS
17 LM0203001 SPRING IDT 3KGF
18 LM0204001 STUD IDT
19 LM0205001 HOLDER IDT
2 LM0422001 CHUTE ASSY IN BR 220V
20 LM0425001 FUSER DRIVE ASSY
21 LM0206001 SPRING TRANSFER ROLL CARTRIDGE L 1.5
22 LM0207001 WIRE ASSY FSR EARTH
23 LM0024001 LATCH R
24 LM0208001 SPRING LATCH 1.2KGF
25 LM0209001 SHAFT LATCH
26 LM0210001 PLATE IN T/R
27 LM0211001 ROLL PINCH TURN
28 LM0212001 SPRING PINCH TURN 375
29 LM0213001 ROLL PINCH DUP
3 LM0191001 WIRE ASSY TRANSFER ROLL CARTRIDGE 2
30 LM0214001 SPRING PINCH DUP
31 LM0215001 CHUTE DUP IN
32 LM0025001 LATCH L
4 LM0192001 SPRING TRANSFER ROLL CARTRIDGE R2
5 LM0193001 SHAFT TRANSFER ROLL CARTRIDGE IN
6 LM0194001 WIRE ASSY DISK
7 LM0195001 SPRING DTC 0.2
8 LM0196001 STUD TRANSFER ROLL CARTRIDGE
9 LM0197001 HOLDER SPRING TRANSFER ROLL CARTRIDGE
