Группа запчастей для Brother DCP110C - ENGINE


Группа запчастей для Brother DCP110C - ENGINE
Номер партии Описание Примечание
1 LF7963001 ENGINE UNIT SUPPLY ASSY chg
1-1 LF4764001 CARRIAGE MOTOR
1-10 LF4790001 SENSOR ACTUATOR SPRING
1-11 LF4800001 PF ENCODER DISK
1-12 LP0060001 PAPER FEED MOTOR chg
1-14 LF4809001 SENSOR PCB
1-15 087320616 TAPTITE, CUP S M3X6
1-16 LF4812001 PAPER PULL-IN HOLDER
1-16-1 LF4815001 AUTO SHEET FEEDER ROLLER ASSY add
1-17 LF4818001 FLUSHING CASE
1-18 LF4768001 TIMING BELT ADD
1-2 LF4769001 CR ENCODER STRIP
1-3 000300305 SCREW, BIND M3X3
1-6 LP0555001 STAR WHEEL HOLDER ASSY A chg
1-7 LF7525001 PLATEN chg
1-8 LP0021001 PAPER PRESSURE HOLDER chg
1-9 LF4789001 REGISTRATION SENSOR ACTUATOR
10 LF4759001 PURGE LEVER add
11 LF4762001 CLUCH GEAR add
12 LF4763001 CLUCH GEAR SPRING (SHORTER) add
2 LF7036001 PURGE UNIT
2-1 LG5780001 INK CARTRIDGE/PURGE HP SWITCH HARNESS
3 LF4806001 JAM CLEAR COVER add
4 LF7953001 HEAD COVER ASSY (*2 For models with detachable carriage PCB on the print head) add
4 LF7964001 HEAD COVER ASSY (*1 For models with non-detachable carriage PCB on the print head) chg
5 LP0057001 FFC SUPPORT add
6 LF7954001 CARRIAGE PCB SUPPLY ASSY add
7 087320616 TAPTITE, CUP S M3X6
8 087310815 TAPTITE, CUP B M3X8
9 LF4760001 PURGE LEVER SPRING (LONGER) add
