Каталог запчастей для Canon iR5055 - 250 MAIN DRIVE ASSEMBLY

№	Номер партии	Описание	Примечание
1	XD9-0136-000	RING, E
10	FS3-0167-000	GEAR, 30T
11	FS5-0685-000	GEAR, 24T
12	FS6-0070-000	GEAR, 40T
13	FS6-0091-000	GEAR, 16T
14	FL2-5833-000	GEAR, 76T/27T
15	XG9-0554-000	BEARING,BALL, 6002ZZNRCG16AV2L
16	XG9-0549-000	BEARING,BALL, JMK-688ZZNR D4ML
17	XG9-0550-000	BEARING,BALL, 608ZZ1NRMC3E,
18	FS5-3807-000	PULLEY, 18T
19	FK2-0852-000	CLUTCH, ELECTROMAGNETIC	CL1
2	FA9-2112-000	BUSHING, PL
20	FB5-3005-000	BOSS, FLYWHEEL
21	FK2-3689-000	MOTOR, DC	iR5075/iR5075N M1
21	FK2-0801-000	MOTOR, DC	EXCEPT iR5075/iR5075N M1
22	FS5-2959-000	SPRING, TORSION
23	FS6-0127-000	GEAR, 18T
24	FS6-0084-000	PULLEY, 26T
25	FS5-6328-000	WASHER
26	FS6-0076-020	GEAR, 18T
27	XD9-0137-000	RING, E
3	FB6-5889-000	ELIMINATOR, STATIC CHARGE
4	FB5-4562-000	FLANGE
5	FS7-0645-000	GEAR, 89T
6	FB2-7851-000	FLANGE
7	XA9-0207-000	SCREW
8	FH2-9243-020	CONNECTOR, HIGH VOLTAGE
9	FH2-9248-000	CONNECTOR, HIGH VOLTAGE
Fig.250	FM2-3018-000	MAIN DRIVE ASSEMBLY	EXCEPT iR5075/iR5075N
Fig.250	FM2-9662-000	MAIN DRIVE ASSEMBLY	iR5075/iR5075N
