Каталог запчастей для Konica-Minolta bizhub 240f - DC4-012

Каталог запчастей для Konica-Minolta bizhub 240f - DC4-012
№ Номер партии Описание Примечание
101 D88 - 05330 - 6X FBS TENSION PULLEY
102 D88 - 05350 - 6X FLANGE B
103 DA7 - 05020 - 6X SHAFT GUIDE
104 DA7 - 05080 - 6X GEAR 65/27P
105 DA7 - 05100 - 5X BRACKET MOTOR FBS
106 DA7 - 05130 - 6X STUD D6 23.2
107 DA7 - 05140 - 6X SPRING C TENSION
108 DA7 - 0515G - 6X LOCK CARRIAGE
109 DA7 - 05160 - 6X SPRING C FG
111 DC4 - 0501B - 6X CHASSIS FBS
112 DC4 - 05100 - 6X GEAR 32/44
113 DC4 - 05170 - 6X STAY FRONT
114 DC4 - 05200 - 6X BRACKET SCANNER PCB FBS
115 DC4 - 05220 - 6X STAY FRONT SUB
116 DC4 - 08020 - 5XX PCB SCANNER
121 DC4 - 2580B - 6X PIECE EXIT RIB
123 DC4 - 08580 - 5XX CABLE-ASSY
125 Z08 - 05630 - 0X BELT(TIMING)
127 ZA1 - 03417 - 40 CABLE-ASSY
128 ZA1 - 03694 - 80 CABLE-ASSY
129 ZA1 - 03603 - 10 MOTOR(STEPING)
130 DFG - S3S3B - 512 CABLE-ASSY
131 ZA1 - 02808 - 30 CORE
134 DC4 - 05230 - 6X SHEET FBS LEFT
135 DC4 - 05240 - 6X PLATE SHIELD PCB SCANNER
136 DC4 - 05250 - 6X PLATE FG MAIN FBS
137 DC4 - 05260 - 6X SHEET INSULATOR A
138 DFG - S3S3B - 506 CBL-ASSY DFG-S3S3B-506(L60)
139 ZA1 - 00921 - 00 CORE
140 ZA1 - 02491 - 00 CORE
141 ZA1 - 03814 - 30 SHEET
142 ZA1 - 03572 - 50 GASKET
143 Z90 - 67805 - 0X SHEET
