Каталог запчастей для Konica-Minolta bizhub C252 - OPTICAL SECTION

№	Номер партии	Описание	Примечание
1	4036 1582 01	COVER
10	4036 1374 02	PLATE
11	4037 6819 01	WIRE HARNESS ASSY
12	4581 2269 04	SHOULDER SCREW
13	4036 1633 01	SEAL
14	4038 1510 01	PLATE SPRING
15	4037 1590 01	BRACKET
16	9335 1400 81	SOLID STATE SWITCH
17	9335 1400 81	SOLID STATE SWITCH	A,A1,B,C,G2,H,J(OPTION)
17	9335 1400 81	SOLID STATE SWITCH	D1,D3,F1, F2,G1,I,K
18	4037 6854 01	WIRE HARNESS ASSY
19	4038 R739 00	LENS/CCD ASSY
2	4036 1366 01	COVER
20	9326 1200 61	FERRITE CORE	C,D1,D3, F2,G1,H,I,J,K
3	4581 1579 01	PLATE SPRING
4	4037 6853 01	WIRE HARNESS ASSY
5	4025 2175 01	CUSHION
6	4038 0113 05	PWB-C
7	9326 1001 11	FERRITE CORE
8	4581 1316 01	SEAL
9	4038 6864 01	WIRE HARNESS ASSY
