Каталог запчастей для Kyocera-Mita TASKalfa 2550ci - Exit Section

№	Номер партии	Описание	Примечание
1	302F929260	PULLEY DU LOW	2F929260
10	302K028190	SPRING SOLENOID A	2K028190
11	302K028300	SHEET EXIT FRAME	2K028300
12	2FM04150	CAP SPRING /B-11 ENCLOSURE A4	5MVM163DN005
13	302K028210	SPRING EXIT PULLEY	2K028210
14	302K324460	SHAFT FEED	2K324460
15	302K328290	GUIDE EXIT PUSH JS	2K328290
16	302K328260	SPRING GUIDE EXIT PUSH	2K328260
17	302K328090	GUIDE EXIT PUSH	2K328090
18	7NXGP1S173LCH01	SENSOR OPT.	NX116910
19	302K046060	WIRE EXIT UNIT2	2K046060
2	302K028280	SPRING GUIDE PULLEY	2K028280
20	302K028070	COVER EXIT SENSOR	2K028070
21	302MV44030	SWITCH EXIT PAPER EMPTY	2MV44030
22	302KK28110	PLATE EXIT	2KK28110
23	302K028320	SHEET PLATE EXIT	2K028320
24	302K028080	ACTUATOR EXIT OVERFLOW LOW	2K028080
25	302K028250	SPRING EXIT EARTH C	2K028250
26	302K094340	PARTS ROLLER EXIT FD SP	2K094340
27	303MA16560	SHAFT GEAR BELT	3MA16560
28	302K028260	GEAR Z23S EXIT	2K028260
29	302K028270	SPRING EXIT EARTH D	2K028270
3	302K094350	PARTS ROLLER EXIT REVERSE SP	2K094350
30	302KP29090	GEAR IDLE Z18S	2KP29090
31	302K394340	PARTS GEAR Z74R-Z22S EXIT SP	2K394340
32	303LJ94150	PARTS SOLENOID FEED SHIFT SP	3LJ94150
33	302K028160	LEVER SOLENOID	2K028160
34	302K028180	PLATE EXIT MOTOR	2K028180
35	302K028310	RUBBER EXIT	2K028310
36	302HN44100	MOTOR REVERSE	2HN44100
37	7YZM610009++H01	ACCESS.SADDLE	YZ042980
38	7YZM610007++H01	ACCESS.SADDLE	YZ023340
39	302K028240	SPRING EXIT EARTH B	2K028240
4	302H702590	BUSH SCREW	2H702590
40	302K028090	ACTUATOR EXIT OVERFLOW UP	2K028090
41	63212210	STATIC ELIMINATOR,EJECT	63212210
5	5MVX111DN003	RING STOPPER /A-49 FEED A4	2A806250
6	302H024370	BUSH 6 EW	2H024370
7	302K028200	SPRING EXIT EARTH A	2K028200
8	302K394350	PARTS GEAR Z22S EXIT SP	2K394350
9	302K028060	GUIDE CHANGE	2K028060
A01	302K094010	PARTS EXIT UNIT SP	2K094010
