Каталог запчастей для Kyocera-Mita TASKalfa 2550ci - Frames 3


Каталог запчастей для Kyocera-Mita TASKalfa 2550ci - Frames 3
Номер партии Описание Примечание
1 303NN02370 RAIL FEED 3NN02370
10 303NN02450 GUIDE PRIMARY FEED 3NN02450
11 302K002230 ACTUATOR PAPER EMPTY 2K002230
12 302K046300 WIRE LIFT FULL 2K046300
13 302K002980 HOLDER CORD SENSOR 2K002980
14 302K002340 RAIL DRUM R 2K002340
15 302K002350 RAIL DRUM L 2K002350
16 302K002360 RAIL DRUM BK 2K002360
17 7NXGP1S173LCH01 SENSOR OPT. NX116910
18 302H024370 BUSH 6 EW 2H024370
19 302K031730 SHAFT BELT CLEANING DRIVE 2K031730
2 302FG07020 PULLEY,CASSETTE RAIL 2FG07020
20 302K031720 GEAR BELT CLEANING DRIVE Z30L 2K031720
21 302K031740 GEAR BELT CLEANING DRIVE Z20L 2K031740
22 302K039080 HOLDER CORD 2K039080
23 302MV46380 WIRE MAIN SW 2MV46380
24 7YZM610011++H01 ACCESS.SADDLE YZ043000
25 302K002110 STAY HANDLE LEFT 2K002110
26 302MV02160 HANDLE COVER LEFT 2MV02160
27 7YZM610009++H01 ACCESS.SADDLE YZ042980
28 302K002820 HOLDER CORD REAR 2K002820
29 302K094041 PARTS PIPE TRANSFER CLEANING ASSY SP 2K094041
3 2FB06710 PIN CASSETTE RAIL 2FB06710
30 302K002C40 HOLDER CORD FRONT 2K002C40
31 302K002620 MOUNT INTERLOCK SW 2K002620
32 7SM010303+++H01 SW.MICRO SM037910
33 302K046081 WIRE FRONT/RIGHT SW 2K046081
34 302K031710 SHAFT TRANSFER CLEANING DRIVE 2K031710
4 302MV02040 STAY FRONT FRAME 2MV02040
5 302K002590 GUIDE ACTUATOR 2K002590
6 302MV06020 HOLDER SENSOR 2MV06020
7 302H702590 BUSH SCREW 2H702590
8 303NN46130 WIRE LIMIT JUNCTION UPPER 3NN46130
9 303NN02143 STAY UPPER FEED 3NN02143
