Каталог запчастей для Ricoh Aficio MP1610L - DUPLEX UNIT 3 (B282)

№	Номер партии	Описание	Примечание
1	B043 4993	Reverser Shelf
10	B043 4991	Coupled Gear - 15/51z
101	0451 3008N	Tapping Screw - M3x8
102	0450 3008N	Tapping Screw - M3x8
103	0313 0060N	Screw - M3X6
104	8 053 383	Bushing - M5
105	0720 0040E	Retaining Ring - M4
106	0451 3006N	Tapping Screw - 3x6
11	B261 4994	Stepper Motor Bracket
12	B282 4710	Stepper Motor:Assy
13	B261 4984	DC Solenoid:Assy
14	B123 4502	Middle Reverse Guide Plate
15	B123 5253	Harness - Duplex Sensor
16	B123 4506	Reverse Roller Ground Plate
17	G104 5141	Knob Screw:M3
2	B261 4989	Reverse Roller
3	B121 4490	Antistatic Brush
4	B043 4975	Gear - 18Z
5	B269 4981	Guide Plate:Reverse:Left Upper
6	B123 4973	Reverse Paper Feed Sensor Bracket
7	B123 5245	Harness:Duplex:Ground Wire
8	B043 4998	Rail - Reverser Shelf
9	GW01 0007	Photo Refiection Sensor:Exit
