Каталог запчастей для Ricoh Aficio MP171 - ARDF 5 (D068/D069/D072)


Каталог запчастей для Ricoh Aficio MP171 - ARDF 5 (D068/D069/D072)
Номер партии Описание Примечание
1 B872 1923 Torsion Spring: Pressure: Front
10 B872 1414 Hinge: Left
101 11 050 511 Harness Clamp - LWS-0306ZC
102 11 050 508 Harness Clamp - LWS-0711
103 0450 3008N Tapping Screw - M3x8
104 0454 3006Q Tapping Screw - M3x6
105 0450 3010N Tapping Screw - M3x10
106 0451 3010N Tapping Screw: 3x10
107 0450 3006N Tapping Screw - M3x6
11 B872 1421 Hinge: Right
12 B872 6041 Decal: Lever: Knob
13 B351 4322 Tape: Pressure Plate
14 B872 4512 Pressure Plate
15 B872 4513 Tape: Pressure Plate: Left
16 B872 1941 Guide: Base: Driven
17 B872 1916 Bracket: Pressure Plate
18 B872 1915 Holder: Bracket: Pressure Plate
19 B872 1914 Spacer: Pressure Plate
2 B872 1921 Lever: Driven: Pressure
20 B262 1667 Holder: Hinge: Left
21 B262 1668 Holder: Hinge: Right
3 B872 1924 Torsion Spring: Pressure: Rear
4 B872 1922 Roller: Driven: Scanning: Front
5 B872 1934 Bushing: Exit
6 B872 1931 Exit Roller: Driven
7 B872 1933 Compression Spring: Exit: Driven
8 B872 1912 Cap: Paper Feed Sensor: Base
9 B872 1114 Bracket: Side Plate: Rear Right
