Каталог запчастей для Ricoh Aficio MP1911 - Platen Cover (B24562)

№	Номер партии	Описание	Примечание
1	54 482 804	Platen Cover Sheet
10	B245 1383	Bracket:Pressure Plate:Fix:PANDA
101	0450 4012N	Tapping Screw:4x12
2	B406 1393	Platen Cover Pad
3	G329 1350	Flex Hinge - Platen Cover
4	B406 1387	Front Platen Cover
5	B406 1397	Original Holder
6	B406 1392	Rear Platen Cover
7	G329 1355	Hinge:Pressure Plate:Assy
8	B245 1231	Pressure Plate:Assy
9	A548 6121	Screw - M4
