Каталог запчастей для Ricoh Aficio MP5500SP - FRAME SECTION 4


Каталог запчастей для Ricoh Aficio MP5500SP - FRAME SECTION 4
Номер партии Описание Примечание
1 B247 6177 Bracket - Paper Size Sensor
10 B098 6693 Shield:Frame:Paper Bank:Upper
101 0451 3006N Tapping Screw - 3x6
102 0453 3006N Tapping Screw - M3x6
103 0720 0040E Retaining Ring - M4
104 0451 4008N Tapping Screw:4x8
105 1105 0516 Clamp
106 0954 3008N Screw - M3X8
107 1105 0522 Edge Saddle - Les0510
108 1105 0488 Harness Clamp
11 B065 6191 Side Plate - Paper Tray
12 B247 6174 Bracket:Positioning:Paper Tray:Assy
13 AX40 0176 Heater:115V:18W:Upper
13 AX40 0178 Heater:240V:18W:Upper
14 B140 6221 Heat Sink:Heater:Lower:Sub-assy
15 AW50 0010 Push Switch
16 B247 6800 Harness - Paper Size Sensor
2 AA06 0534 Tray Lock Spring - 19mm
3 B065 6136 Tray Lock Arm
4 B132 6692 Slide Rail:Left:Sub-assy
5 B065 6783 Slide Rail Base
6 B132 6693 Slide Rail:Right:Assy
7 AH01 2031 Caster:1470n
8 AA14 3803 Flanged Hexagonal Head Bolt:Caster
9 AA14 3798 Hexagonal Bolt:M12x35
