Каталог запчастей для Ricoh Aficio MPC7500SP - Drive Section 6


Каталог запчастей для Ricoh Aficio MPC7500SP - Drive Section 6
Номер партии Описание Примечание
1 B132 6764 Bracket:Connector:Right
10 B132 6762 DC Solenoid:Coupling:Assy
11 B132 6765 DC Solenoid:Lock:Assy
12 AA06 3902 Spring:Connector:Tandem LCT
13 AA13 2203 Spacer - 6mm
2 D014 5396 DC Harness - Bank Rear
3 AA06 3268 Connector Spring
4 B132 6726 Bracket:Arm:Assy
5 B132 6763 Bracket:Connector:Left
6 B065 6769 Lock Arm
7 B247 6753 Lock Spring - Large
8 B132 6759 DC Motor:Rise:Tandem Lct:Assy
9 B247 6754 Lock Spring - Small
