Каталог запчастей для Ricoh Aficio SP4400SF - Electronics

№	Номер партии	Описание

1	VR42 0078	Board Controller Board: 40X5829
10	VR42 0035	Sensor Toner Level: 40X5385
11	VR42 0087	Supply 110V Power ASM: 40X5842
12	VR42 0023	Sensor Media Input: 40X5366
13	VR42 0026	Solenoid Manual Feed: 40X5369
14	VR42 0028	Clutch MpF Feed: 40X5371
16	VR42 0027	Clutch Media Feed (ACM): 40X5370
19	VR42 0036	LSU: 40X5387
2	VR42 0067	Cable Lsu Hsync Extension: 40X5816
22	VR42 0058	Fan Controller Board: 40X5805
3	VR42 0081	Cable Stairway: 40X5832
4	VR42 0082	Cable Controller Board: 40X5833
5	VR42 0016	Fuser 110V: 40X5344
6	VR42 0022	Sensor Duplex: 40X5365
7	VR42 0019	Sensor Access Door Open: 40X5360
8	VR42 0037	Fan Cooling: 40X5392
9	VR42 0079	Board Engine Control Board: 40X5830
