Каталог запчастей для Ricoh Aficio SP9100DN - TRANSFER BELT UNIT 2

№	Номер партии	Описание	Примечание
1	AD04 1126	Transfer Belt Cleaning Blade
10	B247 3911	Toner Collection Coil
11	AD04 7025	Exit Seal
12	A229 3934	Tape
13	B247 3914	Agitator
14	AA08 2101	Bushing - 6x10x6
15	B065 3918	Toner Collection Gear Coil
16	B065 3928	Cleaning Roller Terminal
17	A229 3910	Front Bushing
18	B065 3922	Electrode Plate Cover
19	B065 3920	Idle Gear - 1
2	B065 3962	Spring Plate
20	B065 3921	Idle Gear - 2
21	B247 3966	DC Solenoid 24v
22	AA08 2058	Bushing - 6x10x9mm
23	A229 3911	Rear Bushing
24	AB01 4176	Cam Gear - 37z
25	B065 3955	Entrance Guide Plate
26	AZ32 0164	Power Pack
27	B247 3976	Harness - Transfer Unit
3	B247 3965	Lever Shaft
4	B065 3963	Lever
5	B065 3964	Bushing
6	B247 3961	Shaft - On-off
7	AA06 3877	Spring
8	B247 3925	Cleaning Roller
9	AA13 2024	Spacer - M6
