Каталог запчастей для Samsung CLX3160FN - ADF Motor


Каталог запчастей для Samsung CLX3160FN - ADF Motor
Номер партии Описание Примечание
1 JC96-03915A ELA HOU-ADF MOTOR
1 JC66-00458A GEAR-IDLE 35 ADF
10 JB72-00844A PMO-WHITE CLUTCH SUB 2
11 JC31-00036A MOTOR STEP-ADF
12 JC61-00387A SPRING ETC-PAD
13 JC61-01659A BRACKET-P-GEAR L
14 JC66-00322A GEAR-CLUTCH 3
15 JC66-00454A LINK-M-SWING ADF
16 JC66-00455A GEAR-58/25 ADF
17 JC66-00456A GEAR-40/21 ADF
18 JC66-00457A GEAR-SWING 31/20 ADF
2 6003-00026 SCREW-TAPTITE
20 JC66-00556A IMPELLER-ADF
21 JC66-00557A GEAR-REMOVE ADF
22 JC39-00640A HARNESS-ADF GND
3 6031-00001 WASHER-PLAIN
33 JC63-01148A SHEET-LIU
4 6031-000023 WASHER-PLAIN
5 6031-001511 WASHER-PLAIN
6 6044-000125 RING-E
7 6044-00015 RING-C
8 JB66-00101A GEAR-CLUTCH 2
9 JB70-00070A IPR-WASHER WAVE
