Каталог запчастей для Samsung CLX3185 - MAIN

№	Номер партии	Описание	Примечание

0	CLX-3185FN/FW CLX-3186FN	4 in 1 model
0	CLX-3185/N/W CLX-3186/N	3 in 1 model
1	JC44-00190A	HVPS
10	JC95-01195A	COVER-REAR
11	JC95-01196A	COVER-FRONT
12	JC96-04826B	ELA UNIT-LSU
13	JC96-05823A	CARTRIDGE-TONER Y	Sales
14	JC96-05824A	CARTRIDGE-TONER M	Sales
15	JC96-05825A	CARTRIDGE-TONER C	Sales
16	JC96-05826A	CARTRIDGE-TONER K	Sales
17	JC96-05827A	CARTRIDGE-DRUM	Sales
18	JC96-05874B	CARTRIDGE-TRANSFER
19	JC97-03788AS	SCANNER	3 in 1 / Refer to 9.
2	JC44-00096C	SMPS	220V
2	JC44-00095C	SMPS	110V
20	JC97-03798AP	SCANNER	4 in 1 / Refer to 10.
22	6003-000196	SCREW-TAPTYPE
23	6003-000269	SCREW-TAPTYPE
25	JC39-00515A	CBF SIGNAL-LIU FFC	3185FN/FW, 3186FN
26	JC39-01404A	HARNESS-BLDC
28	JC39-01363A	HARNESS-SMPS_SIGNAL
29	JC39-01364A	HARNESS-SMPS_POWER
3	JC90-00997A	CASSETTE
31	JC61-02368A	HOUSING-HARNESS
32	JC61-02549A	HOLDER-LINK
33	JC63-01574A	COVER-CABLE
34	JC63-01575A	COVER-HARNESS
35	JC63-01793A	COVER-HARNESS
36	JC63-02718A	COVER-SWITCH
38	JC92-02020A	PBA SUB-ADF	3185FN/FW, 3186FN
39	JC92-02277G	PBA-MAIN	3185FW/TEG/XEC
39	JC92-02279A	PBA-MAIN	3185/3186
39	JC92-02277B	PBA-MAIN	3185FN/3186FN
39	JC92-02277C	PBA-MAIN	3185FW/others
4	JC91-00977A	FUSER	110V
4	JC91-00978A	FUSER	220V
40	JC92-02303A	PBA-FAX CARD	3185FN/FW, 3186FN
41	JC96-01673A	ELA UNIT-TERMINAL TR S
42	JC97-01771A	MEA UNIT-TERMINAL S
43	JC97-03021A	MEA UNIT-TANK WASTE
5	JC93-00183A	DRIVE
6	JC93-00207E	FRAME
7	JC63-02712C	COVER-RIGHT	3185N/3186N
7	JC63-02712B	COVER-RIGHT	3185FN/FW, 3186FN
7	JC63-02712A	COVER-RIGHT	3185/3186
8	JC95-01193A	COVER-LEFT
9	JC95-01194B	COVER-MIDDLE	3185FN/ 3186FN
9	JC95-01194A	COVER-MIDDLE	3185/3186
9	JC95-01194C	COVER-MIDDLE	3185FW
9	JC95-01194D	COVER-MIDDLE	3185N/ 3186N
