Каталог запчастей для Samsung SCX6545NX - Base Frame

№	Номер партии	Описание

0	JC96-04903A	ELA HOU-BASE FRAME
1	JC61-01337A	BASE-P-PLATE
10	0604-001095	PHOTO-INTERRUPTER
11	JC39-00790A	CBF HARNESS-REGI
12	JC97-02704A	MEA UNIT-ACT READY
12-1	JC61-01422A	HOLD-M ACT READY
12-2	JC61-01435A	LEG-M_ACT READY DP
12-3	JB61-00076A	SPRING ETC-TORSION DOC (CC2-F)
15	JC61-01341B	HOUSING-BASE RIGHT
16	3001-002207	SPEAKER
17	JC39-00792A	HARNESS-MP_SPK
18	JC61-01423A	BRACKET-P-ARM FRIC
19	6107-001258	SPRING-ES
2	JC61-01312A	PLATE-P-BEAM BASE
20	6107-001263	SPRING-TS
21	JC66-00959A	LEVER-M_ARM FRICTION
22	6044-000125	RING-E
23	JC61-00423A	BUSH-6_D
24	JC61-01313A	GUIDE-M_PICKUP BASE
25	JC63-00795A	SHEET-GUIDE FILM BASE
26	JC61-01314A	GUIDE-P-SHIELD SMPS
27	JC97-02705A	MEA UNIT-FEED IDLE MP
27-1	JC66-01027A	ROLLER-RUBBER IDLE
27-2	JC61-00046A	SPRING ETC-TR R HAWK
27-3	JC61-01434A	HOLDER-M_BUSHING IDLE
27-4	JC61-00424A	BUSH-4
3	JC61-01342B	HOUSING-BASE LEFT
31	6107-001258	SPRING-ES
32	JC61-01297A	GUIDE-M_FEED IDLE MP
33	JC97-02290A	MEA UNIT-RETARD
33-1	JC61-01348A	BRACKET-P-RETARD
33-2	JC66-00937A	SHAFT-RETARD S
33-3	JC66-00939A	SHAFT-LOCK
33-4	JC66-00938A	SHAFT-RETARD M
33-5	JC67-00126A	COUPLER-TORQUELIMITER
33-6	JC66-00976A	JOINT-M_RETARD
33-7	JC97-02259A	MEA UNIT-ROLLER PU
33-8	JC61-01349A	BRACKET-P-BAR RETARD
34	JC61-01338A	BASE-P-PLATE REAR
35	JC96-04906A	ELA HOU-SIZE SENSOR
35-1	JC96-02127B	ELA HOU-CST SENSOR HAWK16
35-2	JC61-01343A	HOUSING-M_SIZE SENSOR
35-3	JC39-00795A	HARNESS-TRAY_SIZE
35-4	JC63-00794A	GROUND-P-PAPER SIZE
36	JC61-01345A	HOLDER-M_CST L
37	JC61-01340A	BRACKET-P_HANDLE L
38	JC39-00780A	HARNESS-SCF_MAIN
39	JC70-11028A	IPR-GROUND TOP
4	JC61-40001A	FOOT-ML80
40	JC39-00793A	CBF HARNESS-NEAR SEN
41	JC61-01436A	BRACKET-P_HANDLE R
42	6502-000132	CABLE CLAMP
43	6502-001101	CABLE CLAMP
44	JC31-00045A	MOTOR GEARED-P LIFT
49	JC63-00833A	GROUND-P-SHAFT RETARD
5	JC96-05046A	ELA HOU-PICK UP
50	JC61-02262A	HOLDER-P-MP FEED
51	JC97-02260A	MEA UNIT-HOLDER PAD
6	JC61-01347A	BRACKET-P-JOINT BASE
7	JC61-01296A	GUIDE-M_FEED UPPER
8	JC61-01344A	HOLDER-M_CST R
9	JC61-01294A	GUIDE-M_FEED DP
