Каталог запчастей для Xerox WorkCentre 3045 - Feeder 2

№	Номер партии	Описание

1	059K71563	Feed Roll Assembly (with 1-7)
10		Plate BTM
11		Holder BTM L
12		Holder BTM R
13		Follower L
14		Follower R
15	848K49666	Separator Pad Assembly
16		Arm MSI R
17		Spring NF
18		Arm MSI L
19	807E36162	Feed Gear
2		Cam MSI L
20		Spring Feed
3		Roll Core
4		Roll Assy Feed
5		Holder Feed
6		Shaft Feed
7		Cam MSI R
8	815K07610	Bottom Plate (with 9,10)
9		Pad MSI
