Группа запчастей для Brother HL1650/1670N - FRAME DRIVE UNIT

№	Номер партии	Описание	Примечание
1	LJ5052001	MAIN MOTOR ASSY
10	LJ5100001	TONER SENSOR PCB UNIT (RECEPTION)
11	LJ7403001	RUBBER FOOT
12	LJ5925001	GEAR 21 H
13	UL9069001	CONDUCTOR BEARING 5
14	LJ5533001	CONDUCTOR BEARING H
15	LJ5117001	FAN MOTOR 60
16	LJ8363001	DX SENSOR PCB ASSY
17	LJ8724001	TAPE 60X12
18	LE1169001	USB GROUND PLATE
19	087320615	SCREW, CUP S TITE 3X6
2	LJ5053001	FEED SOLENOID ASSY
20	085411015	TAPTITE, BIND B M4X10
21	000300415	SCREW, BIND M3X4
22	085310815	TAPTITE, BIND B M3X8
23	LJ5051001	FUSER DRIVE GEAR
24	LJ5930001	FEED ROLLER GEAR SHAFT
25	LJ5114001	SPRING, EXTENSIONS P/R
26	LJ5107001	COVER GLASS HOLDER H
27	LJ5112001	GEAR 60 P/R add
28	LJ5115001	GEAR 72MP add
29	UL9023001	COVER GLASS add
3	LJ5058001	SOLENOID ASSY P/R
30	LJ5109001	PENDULUM GEAR ADD
31	LJ5064001	DEVELOP JOINT ADD
32	LJ5065001	JOINT SPRING ADD
4	LJ5060001	SOLENOID ASSY MP
5	LJ5208001	LOCK LEVER SPRING
6	LJ5307001	TONER LED PCB UNIT (EMISSION)
7	LJ8357001	SOL RELAY PCB ASSY
8	LJ5088001	REVERSING SWITCH SOLENOID
9	LJ5015001	T-BELT B40S2M142
