Группа запчастей для Brother HL5380DN - FRAME L&DRIVE UNIT

№	Номер партии	Описание	Примечание

1	LU7026001	MAIN FRAME L UNIT, HL-5340D
1	LU7146001	MAIN FRAME L UNIT 70, HL-5370DW/5370DWT
1	LU7139001	MAIN FRAME L UNIT 80, HL-5350DN/5350DNLT/5380DN/5380DN-MOF
1-1	LU7214001	DEVELOP JOINT
1-10	LJ9940001	INTERLOCK SW ASSY
1-11	LJ9942001	RELAY REAR PCB ASSY
1-12	LM5085001	NEW TONER ACTUATOR
1-13	LM5086001	NEW TONER ACTUATOR SPRING
1-14	LJ7403001	RUBBER FOOT
1-15	LJ9945001	CONNECTOR 54702-1219
1-16	LM5011001	EJECTOR SOLENOID
1-17	087320616	TAPTITE CUP S M3x6
1-18	085311016	TAPTITE BIND B M3x10
1-19	085311016	TAPTITE BIND B M3x10
1-2	LM5047001	MAIN MOTOR ASSY
1-20	LM5043001	DEV GEAR 37R JOINT DRIVE
1-21	LM5080001	DRIVE RELEASE LINK
1-22	LM5079001	DRIVE RELEASE CAM	add
1-23	087210616	TAPTITE CUP B M2X6	add
1-3	LM5048001	FUSER GEAR 39 H/R DRIVE
1-4	LM5058001	REGISTER SOLENOID ASSY
1-5	LM5062001	MP SOLENOID ASSY
1-6	LM5067001	T1 SOLENOID ASSY
1-7	LJ9935001	TONER SENSOR PCB ASSY
1-8	UL9037001	PT SENSOR HOLDER
1-9	LJ9938001	RELAY FRONT PCB ASSY
2	LM5104001	GEAR 17 MP ROLLER DRIVE
3	LM5103001	GEAR 20 T1 ROLLER DRIVE
4	LM5102001	GEAR 17 FEED ROLLER DRIVE	ADD
