Группа запчастей для Brother MFC760 - MAIN CHASIS

Группа запчастей для Brother MFC760 - MAIN CHASIS
№ Номер партии Описание Примечание
(1-11-1) UU1454001 CARRIAGE TIMING BELT
*1 LE2110001 IDLE GEAR 23
*11 LE3079001 CARRIAGE ASSY (SUPPLY ASSY INCLUDING CR DRIVE BELT AND FLAT CABLES)
*12 UU1077001 CARRIAGE RAIL
*13 UU1078001 ECCENTRIC BUSHING L
*14 UU1079001 ECCENTRIC BUSHING R
*2 LE2111001 ARM 12.3 ASSY
*27 LE2933001 PAPER FEED ROLLER
*28 UU1094001 PAPER FEED ROLLER GEAR L
*29 UU1092001 SPACER
*3 048030345 RETAINING RING, E3
*30 048080345 RETAINING RING, E8
*46 LE2117001 LOWER CHUTE ASSY
*46-1 UG6609001 PAPER EJECTION/CASSETTE SENSOR PCB
*46-2 LG2021001 PAPER EJECTION/CASSETTE SENSOR HARNESS
*46-3 LE2119001 PAPER EJECTION SENSOR ACTUATOR
*46-4 LE2120001 CASSETTE SENSOR ACTUATOR
*46-5 UD4336001 ACTUATOR SPRING
*6 UU1047001 PAPER EJECTION ROLLER
*7 UU1049001 PAPER EJECTION ROLLER GEAR
*8 UU1290001 CONDUCTIVE BUSHING
*9 0A5260805 TAPTITE, PAN 2.6X8DB
10 UU1050001 IDLE GEAR EJECTION
15 UU1081001 IDLE PULLEY HOLDER
16 UD6023000 IDLE PULLEY
17 UD6025001 IDLE PULLEY SHAFT
18 LE0010001 TENSION SPRING
19 UD6014001 ENCODER STRIP
20 UD6012001 SPRING, EXTENSION
21 UU1088001 FFC HOLDER
22 UU1286001 IDLE PULLEY STOPPER
23 0A5300805 SCREW, PAN (S/P WASHER) M3X8
24 UU1476001 BUSHING LOCK
25 UG5569000 FLAT CORE
26 UU1459001 CORE SUPPORT
31 UU1428001 IDLE GEAR P720
32 UU1108001 STAR WHEEL HOLDER ASSY
33 LE2759001 PAPER PRESSURE HOLDER ASSY
34 UU1115001 PRESSER ROLLER SPRING
35 UU1116001 PLATEN
36 UU1117001 PLATEN FRAME
37 087320616 TAPTITE, CUP S M3X6
38 UU1315001 FLUSHING FOAM GUTTER
39 LE2760001 PAPER PRESSURE HOLDER L
4 LE3940001 CARRIAGE MOTOR
40 LE2761001 PAPER PRESSURE HOLDER R
41 LE2479001 PAPER FEED MOTOR
42 UU1446001 PF DRIVE BELT
43 UU1450001 TENSION PLATE ASSY
44 UU1444001 SPRING
45 048040345 RETAINING RING, E4
47 087411015 TAPTITE, CUP B M4X10
48 UU1449001 FLUSHING FOAMS PACK
49 UU1199001 LOWER FLUSHING FOAM
5 0A5300605 SCREW, PAN (S/P WASHER) M3X6
50 UU1200001 UPPER FLUSHING FOAM
