Каталог запчастей для Canon iR1750i - 130 CONTROL PANEL ASSEMBLY

№	Номер партии	Описание	Примечание
1	FC0-0969-000	HINGE, 1
10	FC0-3272-000	KEY TOP, SYSTEM, 2
11	FC0-3273-000	KEY TOP, SYSTEM, 1
12	FC0-3274-000	KEY TOP, SYSTEM, 3
13	FC0-3275-000	KEY TOP, START, LED
14	FC0-3300-000	HINGE, 2
15	FK3-1416-000	CABLE, CPU-TEN KEY FLAT
16	FK3-1417-000	CABLE, CPU-SYSTEM KEY FLAT
17	FK3-1418-000	CABLE, CPU-LCD FLAT
18	FM4-7810-000	CONTROL PANEL CPU PCB ASSY
19	FM4-7811-000	TEN KEY PCB ASSY
2	FC0-3257-000	SHEET, TOUCH PANEL
20	FM4-7812-000	SYSTEM KEY PCB ASSY
21	FL3-4870-000	COVER, CONTROL PANEL, FRONT, 1	KR
21	FL3-4867-000	COVER, CONTROL PANEL, FRONT, 1	AU, SG ,HK, LTN
21	FL3-4871-000	COVER, CONTROL PANEL, FRONT, 1	TW
21	FL3-4866-000	COVER, CONTROL PANEL, FRONT, 1	US, CA, LTN
21	FL3-4868-000	COVER, CONTROL PANEL, FRONT, 1	EUR
22	FC0-3256-000	COVER, CONTROL PANEL, FRONT, 2
23	FC0-3269-000	PLATE, HINGE
3	FC0-3261-000	KEY TOP, TEN
4	FC0-3262-000	COVER, LED
5	FC0-3263-000	KEY TOP, RESET
6	FC0-3264-000	KEY TOP, START
7	FC0-3265-000	KEY TOP, STOP
8	FC0-3266-000	KEY TOP, VOLUME
9	FC0-3267-000	DIAL, CONTRAST
Fig.130	FM4-8056-000	CONTROL PANEL ASSEMBLY	KR
Fig.130	FM4-8054-000	CONTROL PANEL ASSEMBLY	EUR
Fig.130	FM4-8057-000	CONTROL PANEL ASSEMBLY	TW
Fig.130	FM4-8053-000	CONTROL PANEL ASSEMBLY	AU, SG, HK, LTN
Fig.130	FM4-6515-000	CONTROL PANEL ASSEMBLY	US, CA, LTN
