Каталог запчастей для Canon iR2520i - 104 INTERNAL COMPONENTS 1

№	Номер партии	Описание	Примечание
1	VS1-8412-021	CONNECTOR, SNAP TIGHT, BL
10	XD9-0136-000	RING,E
11	XH9-0136-000	FOOT, RUBBER
12	FC9-0544-000	BUSHING
13	FC5-1358-000	COLLAR, FIXING DELIVERY
14	FU7-2941-000	SPRING, RETAINING
15	FC9-0989-000	SPRING, CONTACT
16	FC9-0990-000	SPRING, CONTACT
17	FC9-0991-000	SPRING, CONTACT
2	FC8-6380-000	CLIP
3	FC9-0545-000	BUSHING
4	FK2-9154-000	CLUTCH	CL1
5	XA9-1567-000	SCREW, RS, M3X8.5
501	XD3-1200-122	PIN,SPRING
6	XD9-0137-010	RING, E
7	FC9-0552-000	ROLLER, REGISTRATION PRESSURE
8	FU8-0508-000	GEAR, 17T
9	FC9-0562-000	LEVER, RIGHT
Fig.104	NPN	INTERNAL COMPONENTS 1
