Каталог запчастей для Canon iR5065N - 261 CASSETTE PICK-UP DRIVE ASSY


Каталог запчастей для Canon iR5065N - 261 CASSETTE PICK-UP DRIVE ASSY
Номер партии Описание Примечание
1 FA9-2112-000 BUSHING, PL
2 FK2-3475-000 MOTOR, STEPPING, DC M12
3 FS4-0145-000 GEAR, 20T
4 FS6-0065-020 GEAR, 64T
5 FS7-0653-000 GEAR, ONE-WAY CLUTCH
6 XA9-0628-000 SCREW, M4X8
7 XD9-0137-000 RING, E
Fig.261 FM2-9665-000 CASSETTE PICK-UP DRIVE ASSY
