83. A12 OPEN/CLOSE PANEL
Каталог запчастей для Canon iR5075 - A12 OPEN/CLOSE PANEL ASSEMBLY
№
Номер партии
Описание
Примечание
1
FC5-2953-000
LEVER, OPEN/CLOSE
10
FU6-2900-000
SPRING, TENSION
11
FU5-2236-000
SPRING, COMPRESSION
12
FU5-2250-000
SPRING, COMPRESSION
13
FC5-3025-020
SHAFT, REGISTRATION ROLLER, 1
14
FU5-6075-000
ROLLER, REGISTRATION, 1
15
FU5-6079-000
ROLLER, REGISTRATION, 2
16
FC5-2962-020
SHAFT, REGISTRATION ROLLER, 2
17
FU5-6074-000
ROLLER, REGISTRATION, 3
18
FM2-1035-000
WIRE, GROUNDING
19
FC5-2961-000
SHEET, CLEANING
2
FC5-2956-000
PLATE, REGISTRATION ADJUSTMENT
20
FC5-2959-000
SHEET, CLEANING
21
FC5-2960-000
SHEET, CLEANING
22
FC5-3016-000
SHEET, CLEANING
23
FC5-3017-000
SHEET, CLEANING
24
FC5-2954-000
SCRAPER
25
FC7-4188-000
ROLLER, REGISTRATION
26
FU6-2899-000
SPRING, COMPRESSION
27
XA9-1031-000
SCREW, MACH. TRUSS HEAD, M4X6
3
FC5-2957-000
LEVER, LATCH
4
FC5-2958-000
SHAFT, LATCH
5
FC5-2963-000
RETAINER, OPEN/CLOSE GUIDE
6
FC7-3146-000
SPRING, LEAF
7
FL2-4587-000
COVER, OPEN/CLOSE
8
FL2-4588-000
GUIDE, OPEN/CLOSE
9
FU5-2234-000
SPRING, COMPRESSION
Fig.A12
FM2-5798-000
OPEN/CLOSE PANEL ASSEMBLY
