Canon iR Advance C2225L
8. 105 INTERNAL COMPONENT
Каталог запчастей для Canon iR Advance C2225L - 105 INTERNAL COMPONENTS 4
№
Номер партии
Описание
Примечание
1
FC8-7978-000
LEVER, TOGGLE, COLOR
10
FC8-8220-000
GUIDE, CROSSMEMBER, LOWER
11
FC8-8530-000
HOLDER, CONNECTOR
12
FC8-8606-000
GUIDE, FRONT
13
FC9-8606-000
SPRING, RETAINING
14
FK2-9199-000
CABLE, FLEXIBLE FLAT
15
FC8-8029-000
CAP, SHUTTER LEVER
16
FU7-2750-000
SPRING, TENSION
17
FU7-2763-000
SPRING, TENSION
18
FE2-1985-000
GUIDE, 2
19
VS1-7177-002
CONNECTOR, SNAP TIGHT, BK
2
FC8-7979-000
LEVER, TOGGLE, BLACK
20
VS1-7177-003
CONNECTOR, SNAP TIGHT, BK
21
VS1-7177-005
CONNECTOR, SNAP TIGHT, BK
22
VS1-7177-006
CONNECTOR, SNAP TIGHT, BK
23
VS1-8412-015
CONNECTOR, SNAP TIGHT, BL
24
VS1-8412-027
CONNECTOR, SNAP TIGHT, BL
25
VS1-8412-029
CONNECTOR, SNAP TIGHT, BL
26
FM3-8182-000
LEFT CABLE ASSEMBLY
27
FM3-8644-000
CABLE, BUFFER CONNECTING
3
FC8-7991-000
LEVER, HOLD, BLACK
4
FC8-7992-000
LEVER, HOLD, COLOR
5
FC8-8026-000
LEVER, SHUTTER, 1
6
FC8-8027-000
LEVER, SHUTTER, 2
7
FC8-8028-000
LEVER, SHUTTER, 3
8
FC8-8032-000
LINK, SHUTTER, 1
9
FC8-8033-000
LINK, SHUTTER, 2
Fig.105
NPN
INTERNAL COMPONENTS 4
