Каталог запчастей для Canon iR Advance C3330i - B12 PAPER PICK-UP COVER ASSY(ADF)

№	Номер партии	Описание	Примечание
1	FU5-1172-000	BUSHING
10	FE3-5427-000	SHUTTER, NOISE-PROOF
11	FE3-5438-000	COUPLING
12	FE3-5439-000	SPRING, COMPRESSION
13	FE3-5441-000	HOLDER, ROLLER
14	FE3-5443-000	STOPPER
15	FE3-5493-000	KNOB, PAPER PICK-UP COVER
16	FL0-1443-000	COVER, PAPER PICK-UP
17	FL0-1444-000	GUIDE, PAPER PICK-UP
18	FM1-D470-000	ADF PAPER PICK-UP ASSEMBLY	[DP]
19	FC9-4968-000	ROLLER, PICK-UP
2	FU5-1626-000	BUSHING
20	FE3-5434-000	GEAR, 22T/22T
21	FE3-5436-000	BUSHING
22	FE3-5437-000	BUSHING
23	FE3-5442-000	LEVER
24	FE3-5445-000	SPRING, LEAF
25	FE3-5468-000	SPRING, TORSION
26	FE3-5509-000	GEAR, 33T
27	FE3-5525-000	LABEL, BLUE
28	FL0-2750-000	SHUTTER
29	FU8-0299-000	GEAR, 20T
3	FU7-2654-000	SPRING, TENSION
30	FU8-0890-000	GEAR, 33T
31	FC6-8971-010	LEVER, STOP
32	FC8-6353-000	JOINT
33	FL0-1431-000	ROLLER, PAPER FEED
34	FC9-4973-000	LEVER, WIDTH SENSOR
35	FM1-F923-000	LED PCB ASSEMBLY
36	FM4-1747-000	SENSOR PCB ASSY	SR9,SR10,SR11,SR12
37	FC8-6403-010	DAMPER, REV. GUIDE RETAINING
4	FU7-2655-000	SPRING, COMPRESSION
5	FU9-0938-000	GEAR, 24T
501	XD9-0333-000	PIN, DOWEL
6	FC5-4323-000	ROLLER, REGISTRATION, 1
7	FC5-4324-000	ROLLER, REGISTRATION, 2
8	FC9-4964-000	COVER, LED
9	FC9-4971-010	LEVER, EMPTY SENSOR
B12	FM1-C226-000	PAPER PICK-UP COVER ASSY	ADF
