Каталог запчастей для Canon iR Advance C5030F - 815 FIXING DELIVERY DRIVE ASSEMBLY

№	Номер партии	Описание	Примечание
1	WG8-5783-000	IC,PHOTO-INTERRUPTER,LG248NL1A	PS41,PS44
10	FU8-0150-000	PULLEY, 30T
11	FU8-0156-000	GEAR, 29T/17T
12	FK2-7304-000	MOTOR	M22
13	VS1-7177-004	CONNECTOR, SNAP TIGHT, BK
2	XA9-0732-000	SCREW,RS,M4
3	XA9-1386-000	SCREW,RS,M3X8
4	XF2-1605-740	BELT, TIMING
5	FS5-9224-020	SCREW,STEPPED,M4
6	FU7-0296-000	GEAR, 23T
7	FU7-0297-000	GEAR, 23T
8	FU7-2481-000	SPRING, TENSION
9	FU7-2534-000	SPRING, TENSION
Fig.815	FM3-5994-000	FIXING DELIVERY DRIVE ASSEMBLY
