Каталог запчастей для Canon iRC3200 - 270 DEVELOPING DRIVE ASSEMBLY

№	Номер партии	Описание	Примечание
1	FH6-1973-020	MOTOR, STEPPING	M12-15 J650-653
2	FU3-0337-000	GEAR, 42T/27T
3	FG3-2326-010	CABLE, DEVELOPING DRIVE	J110, 650-653, 701, 769
3A	VS1-7173-008	CONNECTOR, SNAP TIGHT	J769
3B	WT2-5565-000	CLAMP, CABLE
501	XB3-6300-805	SCREW,RS,M3X8
502	XD2-1100-502	RING,E
503	XD1-1106-212	SHIM
Fig.270	FG6-8966-030	DEVELOPING DRIVE ASSEMBLY
