Каталог запчастей для Canon LBP5480 - 100 EXTERNAL PANELS, COVERS, ETC.


Каталог запчастей для Canon LBP5480 - 100 EXTERNAL PANELS, COVERS, ETC.
Номер партии Описание Примечание
1 FE2-1293-000 LID, USB
10 FE2-1362-000 COVER, CONTROL PANEL, RIGHT
11 FM0-2453-000 REAR COVER ASSEMBLY
12 FM0-2458-000 UPPERCOVER ASSY
13 FM0-2459-000 PAPER DELIVERY TRAY ASSY
14 FM0-2464-000 CONTROL PANEL ASSY
15 FC8-9800-000 PLATE, SHIELD
16 FE2-1320-000 PLATE, SHIELD R
2 FE2-1304-000 COVER, LEFT
3 FE2-1305-000 COVER, LEFT LOWER
4 FE2-1308-000 HANDLE, REAR
5 FE2-1311-000 COVER, REAR RIGHT
6 FE2-1312-000 COVER, RIGHT LOWER
7 FE2-2185-000 COVER, CONTROL PANEL, LEFT
8 FE2-1334-000 COVER, PROTECT., LOWER
9 FE2-1337-000 COVER, CONTROL PANEL, RIGHT
Fig.100 NPN EXTERNAL PANELS, COVERS, ETC.
