Номер партии Описание Примечание
1 RC2-4541-000 BUSHING
10 RC2-5123-000 MOUNT, INTERLOCK SWITCH
11 RC2-5121-000 ARM, INTERLOCK LINK SWITCH
12 FE2-2182-000 GUIDE, DUPLEXING REVERSE
13 RC2-5119-000 LINK, INTERLOCK
14 RC2-5118-000 LINK, INTERLOCK
15 RC2-5117-000 FRAME, INTERLOCK
16 RC2-4831-000 ROLLER, RAIL
17 RC2-5913-000 SHAFT
18 RU6-0536-000 GEAR, 19T
19 RC2-5954-000 LEVER, CARTRIDGE LOCK
2 RC2-4875-000 BUSHING
20 RC2-5957-000 HOLDER, CARTRIDGE LOCK LEVER
21 RC2-5958-000 SPRING, TORSION
22 RC2-5956-000 HOLDER, CARTRIDGE LOCK LEVER
23 RU7-0257-000 GEAR, 27T
24 RC2-4378-000 SPRING, TORSION
25 RU6-2268-000 SPRING, TORSION
26 RC2-4377-000 SPRING, TORSION
27 RC2-5122-000 LINK, INTERLOCK
28 RM1-8176-000 2ND TRANSFER ROLLER ASSY
29 WC4-5171-000 SWITCH
3 RC3-1230-000 HOLDER, CST.POSITIONING,FR.RT.
30 RM1-5732-000 DOOR SWICH ASSY
31 FE2-1295-000 COVER, INNER, FRONT
32 FM0-3298-000 CABLE, FRONT
33 RM1-8146-000 RIGHT CASSETTE RAIL ASSY
34 RM1-8163-000 DENSITY DETECT ASSY
35 RM1-8132-000 P. PICK-UP LOWER GUIDE ASSY
36 FM3-9078-000 INTERMEDIATE TRANS. BELT ASSY
37 FM0-3292-000 CABLE, CONTROL PANEL ASSY
38 RM1-5703-000 CABLE, INTERLOCK SWITCH
39 RM1-5532-000 FRONT LOCK ARM ASSY
4 RC3-1232-000 HOLDER, CST.POSITIONING,RR.RT.
40 RC3-1183-000 GUIDE, OPTION ENTRANCE, INNER
41 RC3-1184-000 GUIDE, OPTION ENTRANCE, OUTER
42 RM1-4952-030 SECONDARY TRANSFER ASSY
43 RM1-4970-060 PAPER DELIVERY ASSY
44 RM1-4969-000 REGISTRATION ASSY
45 RM1-5533-000 REAR LOCK ARM ASSY
5 RC2-4914-000 GUIDE, DOOR LATCH, RIGHT
501 XB4-7401-005 SCREW,TAPPING,TRUSS HEAD,M4X10
6 RC2-4828-000 WIRE, SENSOR PROTECT
7 FM3-9079-000 SENSOR CABLE GUIDE ASSY
8 RC2-5019-000 COVER, INNER, RIGHT LOWER
9 RC2-5120-000 LINK, INTERLOCK
Fig.105 NPN INTERNAL COMPONENTS 3
