Canon LBP6200
2. 101 INTERNAL COMPONENT
Каталог запчастей для Canon LBP6200 - 101 INTERNAL COMPONENTS 1
№
Номер партии
Описание
Примечание
1
FM4-5869-000
FIXING ASSY
100V LBP6200
1
FM1-D616-000
FIXING ASSY
120V LBP6230dw
1
FM1-D615-000
FIXING ASSY
100V LBP6230/6240
1
RM1-7547-010
FIXING ASSY
230V
1
RM1-7546-000
FIXING ASSY
120V LBP6200d
10
XA9-1418-000
SCREW, TP, M3X6
11
XA9-1670-000
SCREW, D, M3X6
12
RC2-9214-000
SPACER, RING
13
RM1-7524-000
ROLLER HOLDER ASSEMBLY
2
FM4-7042-000
ENGINE CONTROL PCB ASSY
230V
2
FM1-F910-000
ENGINE CONTROL PCB ASSY
100V,120V LBP6240,6230,6230dw
2
FM4-7041-000
ENGINE CONTROL PCB ASSY
100V,120V LBP6200,6200d
3
FM1-G877-000
MAIN CONTROLLER PCB ASSEMBLY
LBP6240,6230dw
3
FM4-7182-000
MAIN CONTROLLER PCB ASSEMBLY
LBP6200
3
FM1-G878-000
MAIN CONTROLLER PCB ASSEMBLY
LBP6230
3
FM4-7184-010
MAIN CONTROLLER PCB ASSEMBLY
US,EUR,AU,SG,HK,KR,LTN
3
FM4-7183-000
MAIN CONTROLLER PCB ASSEMBLY
LBP6200d CN LBP6200d
4
RM1-7440-000
DELIVERY SENSOR PCB ASSY
LBP6200,6200d
4
FM1-F912-000
DELIVERY SENSOR PCB ASSY
LBP6240,6230,6230dw
5
RM1-7542-010
FIXING FILM ASSY
230V
5
RM1-7541-010
FIXING FILM ASSY
120V
5
FM4-6984-000
FIXING FILM ASSY
100V
6
RC2-9512-000
LINK, PRESSURE RELEASE
7
RM1-7531-010
SWITCH LEVER ASSY
8
RC2-9208-000
ROLLER, PRESSURE
9
XA9-1420-000
SCREW, W/WASHER, M3X8
Fig.101
NPN
INTERNAL COMPONENTS 1
