Epson Aculaser C1900
5. C485-ME CH-003 (04)
Каталог запчастей для Epson Aculaser C1900 - C485-ME CH-003 (04)
№
Номер партии
Описание
Примечание
04-01
1217503
GEAR
4131-2596-01
04-02
1003474
BUSHING
04-03
1217504
FLANGE
4131-2535-01
04-04
1217505
PULLEY
4131-2595-01
04-05
1217506
DRIVING ASSY
4131-0151-01
04-06
1217507
TIMING BELT
4131-2599-01
04-07
1217508
FLANGE
4131-2560-01
04-08
2077913
WIRE HARNESS ASSY
4131-6832-02
04-09
2077355
FUSION DECELERATION UNIT
4131-0355-02
04-10
2077914
SOLENOID
9321-2100-61
04-11
2077357
RACK DRIVE ASSY
4131-0302-01
04-12
2077917
WIRE HARNESS ASSY
4131-6811-03
04-13
2077916
CLUTCH
9322-1200-11
04-14
2077353
PHOTO INTERRUPTER
4131-0902-01
04-15
1217509
GEAR
4131-2615-01
04-16
1217513
GEAR
4131-2608-01
04-17
1217514
LEVER ASSY
4131-0752-01
04-18
1217515
TENSION SPRING
4131-2621-01
04-19
1217510
GEAR
4131-2602-02
04-20
1058120
TENSION SPRING
4120-1213-02
04-21
1217511
GEAR
4131-2611-01
04-22
1217512
SOUND SHIELD
4131-2805-01
04-23
1213564
PULLEY
4131-2561-01
04-24
1217517
GEAR
4131-2571-01
04-25
1213563
TORSION SPRING
4131-2564-02
04-26
1217518
RATCHET
4131-2563-02
04-27
1213565
DRUM
4131-2592-02
04-28
1217519
BUSHING
4131-2589-01
04-29
1217520
CAM
4131-2562-01
04-30
1217521
WASHER
1200-1342-05
04-31
1217522
GEAR
4131-2559-01
04-32
1217523
GEAR
4131-2553-01
04-33
1217524
GEAR
4131-2552-01
04-34
1217525
GEAR
4131-2549-02
04-35
1217526
TIMING BELT
4131-2593-01
04-36
2077356
SOLENOID
9321-2100-41
