Каталог запчастей для Epson Aculaser C2000 - Main Unit 3


Каталог запчастей для Epson Aculaser C2000 - Main Unit 3
Номер партии Описание Примечание
01 1058053 FUSING UNIT DRIVE ASSY
02 1058054 SCREW
03 1058055 GEAR
04 1058056 DUCT
05 1058057 DUCT
06 2036346 FUN MOTOR
07 2036347 ALIENATION MOTOR ASSY
08 2036345 SOLID STATE SWITCH
09 1047329 STOPPER
10 2036348 STOP PLATE ASSY
11 1058059 CIVER
12 1058060 PROTECTION
13 1058061 COLLAR
14 1058062 RATCHET
15 1058064 TORSION SPRING
16 1058065 REGULATING PLATE
17 1058066 GEAR
18 1058067 GEAR
19 1058068 TORSION SPRING
20 1058069 PAWL
21 1058072 TORSION SPRING
22 1058073 SHUTTER
23 1058075 FUSING UNIT DRIVE 3 ASSY
24 2035702 FUSER UNIT 220V
25 1056731 FUSER OIL ROLL
