Каталог запчастей для Epson Aculaser C2000 - Main Unit 4


Каталог запчастей для Epson Aculaser C2000 - Main Unit 4
Номер партии Описание Примечание
01 2036356 POWER SUPPLY
02 2036349 HV TRANSFORMER
03 1046926 PWB SUPPORT 6.35H
04 2048957 PWB ASSY
05 1058084 REAR COVER
06 1058086 COVER
07 1058087 COVER
08 1031628 COVER
09 1058100 BRACKET
10 1031619 GROUND PLATE
11 2036351 HV TRANSFORMER
11 2049035 HV TRANSFORMER
12 1058088 COVER
13 1047609 PWB SUPPORT 9.53H
14 2036352 FUN MOTOR
15 2036353 SWITCH
16 2036354 HARNESS ASSY
17 1058092 TENSION SPRING
18 1058093 PRESSURE SPRING
19 1058094 CONTACT
20 1058096 GUIDE ASSY
21 2030612 MICRO SWITCH
22 1058097 PWB SUPPORT
23 1058099 EARTH GROUND
