Каталог запчастей для HP LaserJet M880z Enterprise Flow MFP - Covers (M880)


Каталог запчастей для HP LaserJet M880z Enterprise Flow MFP - Covers (M880)
Номер партии Описание Примечание
1 RC3-3692-000CN Cover, right lower
10 RM1-9631-000CN Assembly, face down end tray
11 RM1-9633-000CN Assembly, switch back cover
12 RM2-0294-000CN Assembly, left front cover
13 RM2-0295-000CN Assembly, top cover
14 A2W77-67907 Door, front
15 RC4-1378-000CN Cover, rear
16 RM2-5023-000CN Assembly, switch back tray
17 RM2-5049-000CN Assembly, left cover
18 RC3-3719-000CN Cover, rear upper side
19 RC3-5288-000CN Cover, rear upper front
2 RC3-3713-000CN Cover, rear left
20 RC3-5289-000CN Cover, rear upper rear
21 RC3-5960-000CN Cover, rear upper MFP
22 RC3-5965-000CN Cover, right upper front MFP
23 RC4-1291-000CN Cover, right upper rear MFP
3 RC3-3714-000CN Cover, fuser fan
4 RC3-3718-000CN Cover, front upper
5 RC3-3711-000CN Cover, rear right
6 RC3-3712-000CN Cover, rear right upper
7 RC3-5964-000CN Cover, rear upper B
8 RC3-5991-000CN Cover, face down drive
9 RC4-1386-000CN Cap rear right
A04 RC4-4587-000CN Band, door
