Каталог запчастей для Konica-Minolta bizhub 43 - Figure 35

Каталог запчастей для Konica-Minolta bizhub 43 - Figure 35
№ Номер партии Описание Примечание
1 186139708 HFFV2 OPT DPLX - HSG UPPER ASSY 34PPM
10 186139790 HFFV2 OPT DPLX - GEAR ROLLER
11 186139802 HFFV2 OPT DPLX - GEAR IDLE 29
12 186139815 HFFV2 OPT DPLX - GEAR IDLE 47 34PPM
13 186139823 HFFV2 OPT DPLX - GEAR IDLE 77 34PPM
14 186139836 HFFV2 OPT DPLX - GEAR IDLE 57-37
14 186139844 HFFV2 OPT DPLX - COVER LEFT
16 186139857 HFFV2 OPT DPLX - SWITCH DUPLEX
17 186139878 HFFV2 OPT DPLX - MOTOR DUPLEX
18 186139886 HFFV2 OPT DPLX - PWBA DUPLEX J2
19 186139899 HFFV2 OPT DPLX - FAN DUP J2
2 186139716 HFFV2 OPT DPLX - SPRING PINCH
20 186139906 HFFV2 OPT DPLX - SENSOR DUP
21 186139919 HFFV2 OPT DPLX - HARNESS ASSY DUP SNR
22 186139927 HFFV2 OPT DPLX - SPRING ACTUATOR
23 186139948 HFFV2 OPT DPLX - ACTUATOR DUP 34PPM
24 186139951 HFFV2 OPT DPLX - SPRING DAMPER 34PPM
25 186139969 HFFV2 OPT DPLX - COVER RIGHT
3 186139729 HFFV2 OPT DPLX - ROLL PINCH
4 186139737 HFFV2 OPT DPLX - HARNESS ASSY DUP
5 186139740 HFFV2 OPT DPLX - COVER TOP DUP J2 (SPEC)
6 186139758 HFFV2 OPT DPLX - LEVER LATCH RIGHT
7 186139761 HFFV2 OPT DPLX - LEVER LATCH LEFT 34PPM
8 186139779 HFFV2 OPT DPLX - SPRING LATCH
9 186139782 HFFV2 OPT DPLX - ROLLER DUP
