Каталог запчастей для Konica-Minolta bizhub C350 - MULTI MANUAL FEED SECTION 3

№	Номер партии	Описание	Примечание
1	65JA 8201 0	CLUTCH
10	65JA 4226 0	MEMBER
11	65JA 4218 0	TORSION SPRING
12	65JA 4270 0	GEAR 30T
13	25TU 7542 0	BUSHING
14	65JA 4217 0	CAM
15	65JA 4201 0	PIN
16	65JA 4245 0	HOLDER
17	65JA 4234 0	ACTUATOR
18	65JA 4235 0	TORSION SPRING
19	65JA 4246 0	HOLDER
2	65JA 4255 0	SHIELD PLATE
20	65JA 4216 0	SHAFT
21	65JA 4269 0	ROLLER
22	65JA 4229 0	SHAFT
23	65JA 4265 0	GEAR 18T
24	65JA 4274 0	GEAR 20T
25	111T 7526 0	BUSHING
26	25TU 7785 0	GEAR 20T
27	65JA 4264 0	BRACKET
28	65JA 4248 0	GEAR 16/30T
3	65JA 1564 0	WASHER
4	14GR 8202 0	SOLENOID
5	65JA 4271 0	DRUM
6	28GA 8506 0	PHOTO INTERRUPTER
7	65JA 4256 0	BRACKET
8	65JA 4220 0	HOLDER
9	65JA 4219 0	RATCHET
