Konica-Minolta bizhub C38
2. CONTROL PANEL SECTION
Каталог запчастей для Konica-Minolta bizhub C3850 - CONTROL PANEL SECTION
№
Номер партии
Описание
Примечание
1
A3GN161200
Cover
10
A3GNH00500
PWB Assembly (MCMB)
11
A3GN161301
Cover
12
A3GNN10V00
Sensor Wiring /4
12
A3GNN10F00
Sensor Wiring
13
A108M50100
Photointerrupter
14
A3GN135400
Holder
15
A3GN135500
Lever
16
A3GN190101
Mounting Plate
17
A3GN190700
Mounting Plate
18
A3GN190600
Mounting Plate
19
A3GN190801
Mounting Plate
2
A3GNN10600
Drive Relay harness
20
A3GN191300
Light blocking Sheet
21
A3GN161800
Lens
22
A3GNM71D00
Ferrite core
23
A3GN161000
Cover
24
A3GN190500
Mounting Plate
25
A3GNN12100
Relay harness
26
A3GNN12001
Relay harness
27
A3GN191500
Stopper
28
A011946200
Label Emperon
3
A3GNM71C00
Ferrite core
4
A3GN161701
Cover
5
A3GNR70400
Operation Panel Mounting Plate Assy
6
A3GN161100
Cover
7
A3GN161400
Cover
8
A3GN191401
Cover
9
A3GNM71007
Panel assembly
9
A3GNM71207
Panel assembly
9
A3GNM71107
Panel assembly
