Каталог запчастей для Konica-Minolta bizhub C450 - LED UNIT 2
| № |
Номер партии |
Описание |
Примечание |
|
|
|
| 1 |
4037 0765 00 |
LPH-BLACK ASSY |
(YMC) |
|
| 1 |
4037 0766 00 |
LPH-YMC ASSY |
(BLACK) |
|
| 10 |
4025 2151 01 |
GUIDE |
|
|
| 11 |
4036 2176 01 |
CUSHION |
|
|
| 12 |
4036 1701 01 |
FRAME |
|
|
| 13 |
4004 1805 01 |
SHAFT |
|
|
| 14 |
4004 1719 01 |
PLATE SPRING |
|
|
| 15 |
4004 1712 01 |
GUIDE |
|
|
| 16 |
4025 1702 03 |
ARM |
|
|
| 17 |
4025 2152 01 |
GUIDE |
|
|
| 18 |
4025 1716 01 |
PLATE SPRING |
|
|
| 19 |
4004 1819 02 |
TORSION SPRING |
|
|
| 2 |
4025 2175 01 |
CUSHION |
|
|
| 20 |
4025 1813 02 |
LEVER |
|
|
| 21 |
4025 1703 01 |
TORSION SPRING |
|
|
| 22 |
4036 1705 01 |
BRACKET |
|
|
| 23 |
4036 1814 01 |
GUIDE |
|
|
| 24 |
4025 1720 02 |
PLATE SPRING |
|
|
| 3 |
4036 1815 01 |
GUIDE |
|
|
| 4 |
4036 1704 01 |
BRACKET |
|
|
| 5 |
4004 1807 01 |
PRESSURE SPRING |
|
|
| 6 |
4004 6854 01 |
WIRE HARNESS ASSY |
|
|
| 7 |
4025 2172 02 |
SEAL |
|
|
| 8 |
4037 6061 01 |
ERASE ASSY |
(BLACK) |
|
| 8 |
4036 6062 01 |
ERASE ASSY |
(YMC) |
|
| 9 |
4025 2171 01 |
DUCT |
|
|
