Каталог запчастей для Konica-Minolta bizhub C454e - 2ND PAPER FEED SECTION


Каталог запчастей для Konica-Minolta bizhub C454e - 2ND PAPER FEED SECTION
Номер партии Описание Примечание
1 A161561000 Reinforce Plate D
10 A161560300 Paper feed Frame D
11 A161560600 Ground Plate D
12 A00J617900 Ball Bearing B
13 A161562800 Compressing Coil spring C
14 A161560500 Shaft D
15 A161562400 Gear 26T C
16 A00J663200 Bushing C
17 4131300301 BUSHING C
18 A00J563600 Roller A
19 56AA40490 SHAFT STOPPER 4 C
2 A161578100 Drive Roller C
20 A02E561100 Clutch C
21 A161562300 Gear 34T C
22 A161562600 Gear 28T C
23 A161562000 Shaft D
24 A161562500 Bushing C
25 A161562101 Holder D
26 A161567400 Torsion Spring C
27 A161567300 Lever C
28 A02E560800 Shaft D
29 A02EM20200 Clutch B
3 A0EDM50100 Photoreflector I
30 A2XK709000 Gear 24T C
31 A2XKN10H01 Paperfeed Wiring /2 D
32 A161563000 Compressing Coil spring C
33 A161578700 Cushion C
34 A161568901 Cushion D
35 A5C1562200 Roller A
4 A161578200 Guide Plate D
5 A161N12701 Conveyance Detection harness D
6 A161571100 Mounting Plate D
7 A161560900 Mounting Plate D
8 A161561600 Actuator C
9 A108M50100 Photointerrupter B
