Каталог запчастей для Konica-Minolta bizhub C454e - EXTERNAL PARTS


Каталог запчастей для Konica-Minolta bizhub C454e - EXTERNAL PARTS
Номер партии Описание Примечание
1 A3CEPP2C03 Rear Cover C
10 A3CEPP1M00 Cover C
11 A3CEPP4Q01 Wire Harness Assy D
12 A3CEPP1802 Cover C
13 A143PP8F00 Wire Harness Assy D
14 A3CF116400 Hinge Cover Right C
15 A3CF113900 Hinge Cover Left C
16 A3CF116100 Screw_two step C
17 A143114600 Screw C
18 A3CEPP5B00 Label C
2 9J06M10000 FAN MOTOR C
3 A3CEPP4900 PW Board Assy C
4 A3CFPP2702 Hinge-R C
5 A3CEPP1603 Base Frame C
6 A3CEPP2D03 Front Cover C
7 A3CEPP1900 Reinforce Plate D
8 A3CEPP1D02 Hinge-L C
9 A3CEPP2302 Film C
