Konica-Minolta bizhub C45
53. PAPER EXIT SECTION 2
Каталог запчастей для Konica-Minolta bizhub C454e - PAPER EXIT SECTION 2
№
Номер партии
Описание
Примечание
1
4004590301
ROLL
C
10
A161893600
Cushion
D
11
A161890401
Guide Lever
D
12
A0P0901100
Roll
C
13
A161892100
Spring
C
14
A161890203
Guide Part /Lower
D
15
A0ED897700
Collar
C
16
4036254901
PIN
D
17
A161893800
Seal
D
18
A161891000
Bushing
D
19
A161892300
Mounting Plate
D
2
A161892400
Spring
C
20
A161892000
Spring
D
21
A161R72600
Solenoid Assy
C
22
A161F89001
Caulking(Mounting Plate)
D
23
4163529301
SCREW
C
24
A161890102
Paper exit Main body
D
25
A161893500
Regulating Plate
D
26
A161891301
Pulley 18T
D
27
A161892902
Fixing Part
D
28
A161890300
Roller
C
29
A161895201Old
Paper exit Guide /Lower
D
29
A161895212
Paper exit Guide /Lower
D
3
4025598401
SHAFT
D
30
A161895113
Paper exit Guide /Upper
D
30
A161895102Old
Paper exit Guide /Upper
D
31
A161895800
Pulley 44T
D
32
A161900201
Ground Spring
C
33
A161900300
Ground Spring
C
34
A161900100
Ground Spring
C
4
A161895400
Roller
C
5
1164202801
SHOULDER SCREW
D
6
A0ED891100
Bushing
D
7
A161895502
Ground Contact /Upper
D
8
A161894000
Neutralizing Brush
C
9
A161895600
Ground Contact /Lower
D
