Каталог запчастей для Kyocera-Mita TASKalfa 3500i - Cooling Section

№	Номер партии	Описание	Примечание
1	302K994090	PARTS FAN FUSER FRONT UNIT SP	2K994090
101	7BB200320H	+BIND T.T P SCREW 3X20	BB113430
102	7BB700408H	+BIND T.T S SCREW 4X8 SR	BB105640
2	302GR44080	FAN LSU 60-25	2GR44080
3	302K933580	SEAL DUCT EXIT	2K933580
4	302HN44010	FAN MOTOR	2HN44010
5	302HG02450	SEAL FRAME MIDDLE A	2HG02450
6	302K994350	PARTS FAN COOLING DLP 70 SP	2K994350
7	302FZ94420	PARTS,FAN COOLING CONVEYING SP	2FZ94420
8	302FZ94660	PARTS,FAN IMAGE SP	2FZ94660
