Каталог запчастей для Lexmark X443 - Lower Scanner

Каталог запчастей для Lexmark X443 - Lower Scanner
№ Номер партии Описание Примечание
1-1 56P0036 ADF CCD Cable : 6P+14P
1-10 56P0312 Carrier Lock
1-11 56P0038 Main Image Processor Card
1-12 11B6078 Power Cord, U.S., et al.
1-12 11B6075 Power Cord, Israel
1-12 11B6077 Power Cord, South Africa
1-12 11B6074 Power Cord, Europe
1-12 11B6076 Power Cord, Australia/New Zealand
1-12 11B6073 Power Cord, United Kingdom
1-13 56P0195 Power Supply, 24V/2.5A(60W), 100-240V
1-2 56P0035 ADF Motor Cable : 15P
1-3 56P0033 Transport Motor Pulley
1-4 56P0031 Flatbed Optical Assembly
1-5 56P0308 Flatbed LCD Inverter Card Assembly
1-6 56P0037 Belt
1-7 56P0042 Flatbed Optical Unit Cable
1-8 56P0034 Transport Motor
1-9 56P0309 Flatbed Base
NS 12G0017 SCSI-II Cable : 50P(M)/50P(M)
