Каталог запчастей для Lexmark X656dte - ADF feed and drive


Каталог запчастей для Lexmark X656dte - ADF feed and drive
Номер партии Описание Примечание
1 40X4540 ADF feed / pick roll assembly
10 40X2761 Pick roll position cam assembly
11 40X4605 ADF separator roll and guide
12 40X2747 Torque limiter
13 40X2750 Bushing 6 mm
2 40X4545 Spring
3 40X4543 Feed motor assembly with belt and cable
4 40X4544 Transport motor bracket assembly with cable
5 40X2759 Transport drive gear and pulley kit, rear
6 40X2749 Feed one-way bearing and gear kit
7 40X4542 Pinch roll assembly
8 40X2760 Transport drive gear, pulley, and belt kit, front
9 40X4548 ADF solenoid assembly
