Каталог запчастей для Lexmark X925 - 550 sheet option feeder paper feed


Каталог запчастей для Lexmark X925 - 550 sheet option feeder paper feed
Номер партии Описание Примечание
1 40X6365 Option paperfeed cable
10 40X6235 Timing belt S
11 40X6237 Timing belt L
12 40X6234 Opt tray door closed sensor
13 40X6232 Main interface cable
14 40X6236 Option paperfeed clutch
2 40X1107 Vertical paperfeed sensor
3 40X1111 Type2 feed roll
4 40X1173 Horizontal sensor (paperfeed)
5 40X1106 Retainer clip
6 40X1078 Option tray feed roll
7 40X1077 Option tray pick roll
8 40X1079 Option tray separator roll
9 40X1080 Torque limiter clutch
NS 40X7452 550 sheet paperfeed screw parts pack
